The 1U 19-inch Rackmount 6-Way Power Strip with 16A Circuit Breaker is engineered to deliver safe, centralized, and organized AC power distribution within server racks, data cabinets, telecom facilities, and AV gear enclosures. Built for continuous operation in demanding IT environments, this 1U Power Distribution Unit (PDU) mounts horizontally into any standard 19-inch rack frame, eliminating cable clutter and streamlining power routing.
Enclosed in a rugged, industrial-grade steel/aluminum chassis, the power strip is equipped with an integrated 16 Amp resettable thermal circuit breaker that instantly trips during electrical overloads, protecting expensive switches, routers, and servers from potential damage. Featuring 6 grounded sockets, an illuminated master ON/OFF switch with a protective safety cover, and a heavy-duty 3-core input power cable, this PDU ensures high electrical conductivity, effective heat dissipation, and long-term operational reliability.
Comprehensive Key Features:
Standard 1U 19-Inch Rack Mountable: Compact 1U profile designed for seamless horizontal installation in standard 19" equipment racks and server enclosures.
Integrated 16A Circuit Breaker: Features built-in overload protection that automatically cuts power during current surges or overloads to safeguard connected equipment.
Rugged Heavy-Duty Metal Chassis: Constructed from durable cold-rolled steel / anodized aluminum for high thermal resistance and mechanical strength.
6 Grounded Power Outlets: Provides 6 robust AC output sockets suitable for high-density network hardware setups.
Illuminated Master Switch with Safety Guard: Features a backlit power switch with a protective flip-cover to prevent accidental shutdown.
High-Conductivity Internal Copper Busbar: Premium internal wiring and thick copper contacts ensure stable current delivery without overheating.
Extended Technical Specifications:
Form Factor: 1U 19-Inch Horizontal Rackmount PDU
Number of Outlets: 6 Sockets (Universal / Schuko / C13 depending on model configuration)
Maximum Current Rating: 16 Amps
Voltage Rating: 220V - 250V AC, 50/60 Hz
Maximum Power Output: 3680 Watts (3.68 kW)
Protection Mechanism: 16A Resettable Overload Circuit Breaker / Thermal Switch
Enclosure Material: Industrial Cold-Rolled Steel / Aluminum Alloy
Color / Finish: Black Powder-Coated / Metallic
Input Cord / Cable: Heavy-Duty 3 x 1.5mm² Power Cord (1.8m to 3.0m Length with Schuko / C14 / UK Plug)
Certifications: CE, RoHS, LVD Compliant
