The Ubiquiti UniFi Network Video Recorder Pro Gen2 (Model: UNVR-Pro) is a high-density 2U rackmount NVR console engineered specifically to support comprehensive enterprise video surveillance infrastructures. Equipped with 7 hot-swappable 2.5"/3.5" SATA drive bays, the UNVR-Pro offers massive storage expansion capabilities with automated RAID configurations (RAID 1, 5, or 10) to ensure zero data loss during hard drive failures.
Powered by a quad-core ARM Cortex-A57 processor running at 2.0 GHz alongside 8 GB system memory, the unit natively runs the UniFi Protect software stack, supporting seamless recording and playback for up to 60 4K IP cameras or 180 1080p HD cameras simultaneously. The front panel features a 1.3" LCM touchscreen for real-time storage metrics and system telemetry. For ultra-reliable operational continuity, the UNVR-Pro is equipped with a 10G SFP+ uplink for high-speed network backhaul and a USP-RPS DC inlet to protect against AC power outages.
Comprehensive Key Features:
7 Hot-Swappable HDD Bays: Features 7 front-loading 2.5"/3.5" SATA III bays for high-capacity surveillance storage expansion.
Automated RAID Data Protection: Supports flexible RAID 1, RAID 5, and RAID 10 disk configurations for automated drive failure recovery without data loss.
Massive Camera Scaling: Capable of managing up to 60 4K resolution cameras or 180 1080p HD cameras on a single standalone console.
10G SFP+ High-Speed Link: Equipped with (1) 10G SFP+ optical port and (1) GbE RJ45 interface for high-bandwidth video throughput.
Redundant Power Input: Features an internal AC power supply and an integrated USP-RPS DC power input for failover protection.
1.3" LCM Color Touchscreen: Front-panel display provides quick access to storage capacity status, camera counts, and system health metrics.
Extended Technical Specifications:
1. Hardware & Physical Security:
Model / SKU: UNVR-Pro (UniFi Network Video Recorder Pro)
Dimensions: 442.4 x 325 x 87.4 mm (17.4 x 12.8 x 3.4")
Weight: Without Brackets: 9.20 kg (20.3 lb) | With Brackets: 9.30 kg (20.5 lb)
Enclosure Material: SGCC Steel
Form Factor: 2U Rackmount (Rackmount Kit Included)
Processor: Quad-Core ARM® Cortex®-A57 at 2.0 GHz
System Memory: 8 GB
Drive Bays: (7) 2.5"/3.5" SATA III Hot-Swappable Bays
Display: 1.3" LCM Touchscreen Status Display
2. Networking & Operational Parameters:
Network Interfaces: (1) 10G SFP+ Port, (1) 10/100/1000 Mbps RJ45 Port
Management Software: UniFi Protect
Max. Camera Capacity: Up to (60) 4K Cameras or (180) 1080p HD Cameras
ESD/EMP Protection: Air: ±12 kV, Contact: ±8 kV
3. Electrical & Environmental Parameters:
Power Method: 100–240V AC, 50/60 Hz Universal Input / USP-RPS DC Input (11.5V DC, 13.91A)
Power Supply: Internal 160W AC/DC Power Supply
Max. Power Consumption: 160W
Max. Drive Wattage: 135W
Ambient Operating Temperature: -5°C to 40°C (23°F to 104°F)
Ambient Operating Humidity: 5% to 95% Non-condensing
Certifications: CE, FCC, IC, NDAA Compliant
