Ubiquiti Camera UVC-G6-180-B

Ubiquiti G6 180 – 16MP Panoramic IP Camera with Dual Matrix

Ubiquiti G6 180 (UVC-G6-180-B) is an advanced IP surveillance camera designed for large-area surveillance, both indoors and outdoors. The device is equipped with an optical system using two independent 1/1.8" sensors with a resolution of 8 MP each. These sensors work together to generate images with a combined resolution of 16 MP (7680 x 2160 px at 20 frames per second) and achieve a seamless, panoramic field of view with a 180° horizontal angle. Thanks to precise calibration and software-based offset correction, the camera minimizes image distortion at the frame stitching line. The device natively integrates with the UniFi Protect ecosystem, allowing it to replace several traditional fixed-focus cameras, simplifying infrastructure management.

The camera is powered by a quad-core ARM Cortex-A53 processor that supports Multi-TOPS AI. This enables image analytics, including object detection (people, vehicles, animals), facial recognition, and license plate identification. Communication and power are provided via a single Fast Ethernet port. (10/100 Mb/s) using PoE+ power supply.

The housing is IP66 rated (weatherproof) and IK04 rated (mechanical damage resistant). The camera is also equipped with a heating module that activates automatically during initial startup. This module evaporates any moisture from production and prevents condensation inside the optics during subsequent use. The device has a black housing (a white version is also available).

Key Features

• Matrix resolution: 16 MP (7680 x 2160 px) at 20 FPS

• Image sensor: 2x 1/1.8" 8 MP

• Angles of view (FoV): 180° horizontal, 56.7° vertical Vertical

• Power Standard: PoE+ (supported range 37-57 V DC)

• AI Analytical Engine: Face Recognition, License Plate Reading, Intelligent Object Detection

• Ingress Protection: IP66 (tightness) and IK04 (vandal resistance)

Technical Specifications
