The MikroTik CRS320-8P-8B-4S+RM is MikroTik's first high-power 802.3bt PoE++ rackmount switch, specifically designed to eliminate external power injectors in modern commercial setups, hotels, stadiums, and high-rise smart buildings. Driven by a Marvell Prestera 98DX226S switch chip paired with a dual-core 800 MHz ARM processor and 256 MB RAM, it efficiently manages demanding network topologies, VLAN filtering, and hardware-offloaded Layer 3 routing without performance loss.
The switch features a versatile port configuration consisting of 8x Gigabit PoE ports (802.3af/at delivering up to 30W per port), 8x Gigabit PoE++ ports (802.3bt delivering up to 90W per port) to power resource-intensive equipment like heated outdoor 4K security cameras, digital advertising displays, and PoE lighting systems, alongside an independent Gigabit management port and 4x 10G SFP+ fiber ports for high-bandwidth backhaul. It is built inside a heavy-duty 1U steel enclosure equipped with a default 600W hot-swappable AC power supply unit and an open PSU expansion slot to increase the PoE budget up to 1150W.
Comprehensive Key Features
High-Power PoE++ (802.3bt) Ports: Equipped with 8x 802.3bt Type 3/4 PoE++ ports capable of supplying up to 90W per port alongside 8x 802.3af/at PoE ports (30W per port).
High-Bandwidth Fiber Uplinks: Includes 4x 10G SFP+ optical slots for rapid data trunking and core network interconnection.
Expandable Power Budget: Pre-equipped with a 600W hot-swappable AC PSU, featuring a secondary expansion slot to expand the total power delivery capacity up to 1150W.
Hardware-Offloaded L3 Routing: Driven by the Marvell 98DX226S switch chip supporting line-rate VLAN filtering and Layer 3 hardware routing offloading.
Dual Operating System Support: Flexible boot operation supporting lightweight SwitchOS for pure Layer 2 switching or RouterOS v7 (Level 5) for advanced routing and network isolation.
1U Rackmount Heavy-Duty Enclosure: Rugged metallic 1U chassis with active cooling fans and included cable management brackets for professional rack installation.
Extended Technical Specifications
1. Hardware & Physical Parameters
Model / SKU: CRS320-8P-8B-4S+RM
Dimensions: 0.444 m × 0.235 m × 0.044 m (444 × 235 × 44 mm)
Weight: 3.400 kg
CPU: Dual-Core 98DX226S ARM 32-bit @ 800 MHz
RAM: 256 MB DDR3
Storage: 32 MB Flash
Enclosure Material: 1U Rackmount Heavy-Duty Steel Casing
Status LEDs: Power, User LED, Port PoE Output Indicators (af/at/bt status), Link/Activity LEDs
2. Wireless, Networking & Performance Parameters
PoE Ethernet Ports: 16× 10/100/1000 Mbps RJ45 Ports (Ports 1–8: 802.3af/at; Ports 9–16: 802.3af/at/bt)
Management Ethernet Port: 1× 10/100/1000 Mbps RJ45 Port
SFP+ Cages: 4× 10 Gbps SFP+ Ports
Console Port: 1× RJ45 Serial Console Port
Operating System: MikroTik RouterOS v7 (License Level 5) / SwitchOS
3. Electrical & Environmental Parameters
Power Input: 100–240 V AC (Hot-swappable internal PSU included; 2nd PSU slot available)
Max Total PoE Output Power: 963 W (with dual PSUs equipped)
Max Output Power Per Port: Up to 30W on Ports 1–8 (802.3af/at); Up to 90W on Ports 9–16 (802.3bt)
Max Power Consumption: 600 W (1150 W with secondary PSU attached); 36 W (without attachments)
Cooling Type: Active Cooling (3x temperature-controlled fans)
Operating Temperature: -10°C to 50°C (14°F to 122°F)
