The Ubiquiti Wave MLO5 (Model: Wave-MLO5) is a next-generation 5 GHz wireless CPE bridging unit designed to serve as a high-capacity subscriber terminal in PtMP network topologies. Built around modern Wi-Fi 7 / Multi-Link Operation (MLO) architecture, it leverages multi-channel aggregation to optimize link performance, mitigate interference, and achieve multi-gigabit over-the-air throughput.
Engineered with an integrated high-gain directional dish antenna and built-in Bluetooth management radio, the Wave MLO5 enables rapid alignment and field deployment via the UISP mobile app. It features a 2.5GbE Multi-Gigabit Ethernet port supporting Passive PoE power input and PoE pass-through, simplifying single-cable installations for downstream IP cameras or secondary wireless radios. Enclosed in a UV-stabilized, weather-resistant housing with precision pole-mounting hardware, the Wave MLO5 ensures robust performance in harsh outdoor environments.
Comprehensive Key Features:
Wi-Fi 7 Multi-Link Operation (MLO): Utilizes MLO technology to aggregate multiple 5 GHz channels for maximized throughput and reduced latency.
Massive 5.7 Gbps Aggregate Capacity: Delivers high-speed Wireless Internet Service Provider (WISP) backhaul and subscriber connections.
2.5GbE Uplink with PoE Pass-Through: Equipped with a 2.5GbE RJ45 port supporting PoE input and passthrough to power auxiliary devices.
Integrated High-Gain Antenna: Directional reflector dish optimizes link margin and extends operational PtMP distance.
UISP Centralized Management: Complete integration with Ubiquiti Internet Service Provider platform for remote monitoring, provisioning, and automated firmware updates.
Outdoor-Ready Enclosure: Durable, weather-resistant construction built to withstand high wind loads and extreme temperature variations.
Extended Technical Specifications:
1. Hardware & Physical Security:
Model / SKU: Wave-MLO5 (Wave MLO 5 GHz CPE)
Dimensions: Ø231.0 x 51.5 mm (Ø9.09 x 2.03")
Weight: Without Mount: 1.15 kg (2.54 lbs) | With Mount: 1.38 kg (3.04 lbs)
Enclosure Material: UV-Stabilized Polycarbonate, Aluminum Alloy
Mounting: Precision Pole Mount Kit (Included)
Wind Loading: 110 N at 200 km/h (24.7 lbf at 125 mph)
Color: White
2. Wireless, Networking & Performance Parameters:
Operating Frequency: 5.15 to 5.85 GHz (Regional Dependent)
Wireless Technology: Wi-Fi 7 / Multi-Link Operation (MLO) / Wave Technology
Max. Data Rates: Up to 5.7 Gbps Aggregate Throughput
Uplink Interface: (1) 2.5GbE RJ45 Port (PoE In / Passthrough)
Management Interface: Bluetooth 5.0 / UISP Network
Antenna Gain: Integrated High-Gain Directional Reflector (~23 dBi)
Channel Bandwidths: 20/40/80/160/240/320 MHz
3. Electrical & Environmental Parameters:
Power Method: 24V/48V Passive PoE (Pairs 4, 5+; 7, 8-)
Power Supply: 48V DC, 0.65A 2.5GbE PoE Adapter (Included)
Max. Power Consumption: 18W (Excluding PoE Output)
Ambient Operating Temperature: -40°C to 60°C (-40°F to 140°F)
Ambient Operating Humidity: 5% to 95% Non-condensing
Certifications: CE, FCC, IC
