FG-101F-BDL-950-12 specification |
Miscellaneous |
Compliant Standards | UL, BSMI, ICSA IPSec certified, ICSA Firewall certified, cUL, ICSA Antivirus, CB, FCC Part 15 B Class A, IPv6 Ready, RCM, ICSA SSL-VPN, ICSA IPS |
Networking |
Form Factor | External |
Connectivity Technology | Wired |
Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, 10 Gigabit Ethernet |
Network / Transport Protocol | IPSec |
Performance | VPN throughput (IPSec): 11.5 Gbps ¦ NGFW throughput: 800 Mbps ¦ SSL inspection throughput: 1 Gbps ¦ IPS throughput: 1.6 Gbps ¦ Firewall throughput: 20 Gbps ¦ Threat protection throughput: 700 Mbps |
Capacity | Maximum overlay tunnels: 2500 |
Status Indicators | Power, status, alarm, HA |
Features | Firewall protection, switching, routing, IPv6 support, IPSec Virtual Private Network (VPN), anti-malware protection, web threat protection |
Encryption Algorithm | SSL, 256-bit AES, 256-bit SHA, TLS 1.3 |
Environmental Parameters |
Min Operating Temperature | 32 °F |
Max Operating Temperature | 104 °F |
Humidity Range Operating | 10 - 90% (non-condensing) |
General |
Device Type | Security appliance |
Bundled Services | 1 year UTM Protection Bundle |
Height (Rack Units) | 1U |
Width | 17 in |
Depth | 10 in |
Height | 1.7 in |
Processor / Memory / Storage |
Processors Installed | 1 x Fortinet FortiASIC SOC4 |
Hard Drive | SSD 480 GB x 1 |
Expansion / Connectivity |
Interfaces | 2 x 10Gb Ethernet - SFP+ ¦ 20 x 1000Base-T - RJ-45 ¦ 1 x 1000Base-T (management) - RJ-45 ¦ 1 x network - RJ-45 (DMZ) ¦ 1 x console - RJ-45 ¦ 1 x USB 3.0 - Type A ¦ 10 x Ethernet 1000 - SFP (mini-GBIC) |
Power |
Power Device | Internal power supply |
Installed Qty | 2 |
Max Supported Qty | 2 |
Voltage Required | AC 120/230 V (50 - 60 Hz) |
Power Consumption Operational | 39.1 Watt |
