The Ubiquiti UISP Wave AP (WAVE-AP) is a flagship 60 GHz Point-to-MultiPoint (PtMP) access point designed to deliver multi-gigabit wireless backhaul connectivity for WISP networks and enterprise deployments. Powered by Ubiquiti's advanced Wave Technology, it offers up to 5.4 Gbps total throughput (2.7 Gbps duplex) with a 30° sector coverage. Built to handle mission-critical networks, it features an integrated 5 GHz Wi-Fi 6 (802.11ax) backup radio that automatically ensures uninterrupted link availability during severe weather conditions. Equipped with a 2.5 GbE PoE port and a 10G SFP+ port, the Wave AP simplifies deployment with built-in GPS and Bluetooth connectivity for quick setup via the UISP mobile app.
Key Features:
Multi-Gigabit PtMP Performance: Delivers up to 5.4 Gbps aggregate speed across the low-interference 60 GHz spectrum.
Long-Range Connectivity: Connects up to 15 stations with active links reaching up to 8 km depending on the client device used.
Weather-Resilient 5 GHz Backup: Integrated 802.11ax Wi-Fi 6 backup radio maintains link stability during high rain attenuation.
High-Speed Network Interfaces: Features (1) 2.5 GbE RJ45 PoE port alongside (1) 10G SFP+ port for ultra-fast fiber uplinks.
Rugged Outdoor Design: Encased in an IPX6 weatherproof aluminum alloy and UV-stabilized polycarbonate enclosure rated to withstand 200 km/h winds.
Integrated GPS & Easy Management: Built-in GPS antenna for spatial sync and Bluetooth radio for seamless mobile setup via the UISP app.
Technical Specifications:
Model: WAVE-AP (Wave AP)
Operating Frequency: 60 GHz (57 to 71 GHz range depending on region)
Backup Radio Frequency: 5 GHz (Wi-Fi 6 / 802.11ax)
Total Throughput: 5.4 Gbps (2.7 Gbps Duplex)
Sector Coverage: 30° Azimuth
Antenna Gain: 24 dBi (60 GHz) / 12 dBi (5 GHz)
Networking Interfaces: (1) 2.5 GbE RJ45 Port, (1) 10G SFP+ Port
Max Supported Clients: 15 Stations
Power Method: 48V DC Passive PoE (Included 48VDC, 0.65A PoE adapter)
Max Power Consumption: 24 W
Weatherproofing: IPX6 Rated
| brand | Ubiquiti |
