The Ubiquiti NanoStation AC (Model: NS-5AC) is a compact, high-performance airMAX ac Wireless Bridge designed for long-range Point-to-Point (PtP) links and Point-to-MultiPoint (PtMP) CPE deployments. Operating in the 5 GHz frequency band, the device integrates a high-gain 16 dBi directional panel antenna to deliver high-throughput, low-latency wireless connectivity in a classic, low-profile form factor.
Powered by airOS 8 and Ubiquiti's proprietary airMAX ac technology, the NS-5AC achieves real TCP/IP throughput exceeding 450+ Mbps. It features dual Gigabit Ethernet ports with software-configurable 24V Passive PoE passthrough to power a secondary device, a dedicated 2.4 GHz WiFi management radio for fast mobile setup via the UISP app, enhanced ESD surge protection, and versatile pole or wall mounting hardware.
Comprehensive Key Features:
Integrated 16 dBi Panel Antenna: Built-in high-gain directional antenna provides optimized beam coverage for reliable short-to-medium range PtP and PtMP deployments.
Dual Gigabit Ethernet Ports with PoE Passthrough: Features two 10/100/1000 Mbps RJ45 ports, with the secondary port supporting software-configurable 24V passive PoE output to power an IP camera or secondary radio.
Dedicated 2.4 GHz Management Radio: Integrated 2.4 GHz WiFi management radio allows instant, effortless configuration and setup using the UISP mobile app.
High-Throughput airMAX ac Engine: Powered by custom airMAX ac TDMA protocol delivering up to 450+ Mbps real TCP/IP throughput with superior spectral efficiency.
Compact Weatherproof Design: Durable, UV-stabilized outdoor plastic enclosure engineered to withstand harsh environmental conditions and extreme temperatures.
Advanced airOS 8 Operating System: Includes real-time airView spectrum analysis, dynamic channel selection, and comprehensive link performance telemetry.
Flexible Mounting Options: Includes hardware for fast pole mounting as well as wall surface mounting.
Extended Technical Specifications:
Hardware & Physical Parameters:
Model / SKU: NS-5AC (NanoStation AC)
Dimensions: 257 x 84 x 30 mm (10.12 x 3.31 x 1.18")
Weight: 233 g (8.22 oz)
Enclosure Material: UV-Stabilized Outdoor Plastic
Processor: MIPS 74Kc at 720 MHz
System Memory: 64 MB DDR2 SDRAM
Mounting: Pole-Mount and Wall-Mount (Hardware Included)
Wireless, Networking & Performance Parameters:
Operating Frequency: Worldwide: 5150 – 5875 MHz (USA / FCC: 5725 – 5850 MHz)
Management Radio: 2412 – 2472 MHz
Antenna Gain: 16 dBi
Max. Output Power: 25 dBm
Networking Interfaces: (2) 10/100/1000 Mbps Gigabit Ethernet RJ45 Ports
Wireless Protocols: airMAX ac (TDMA Mode), 802.11ac
Maximum Throughput: 450+ Mbps Real TCP/IP
Channel Bandwidths: PtP Mode: 10/20/30/40/50/60/80 MHz | PtMP Mode: 10/20/30/40 MHz
Electrical & Environmental Parameters:
Power Method: 24V Passive PoE (Pairs 4, 5+; 7, 8 Return)
Power Supply: 24V, 0.5A Gigabit PoE Adapter (Included)
Max. Power Consumption: 8.5W
PoE Passthrough Output: 24V Passive PoE (Software-Enabled, Pin 4, 5+; 7, 8-)
ESD/EMP Protection: Air: ±24 kV, Contact: ±24 kV
Ambient Operating Temperature: -40 to 70° C (-40 to 158° F)
Ambient Operating Humidity: 5 to 95% noncondensing
Regulatory Certifications: CE, FCC, IC
| brand | Ubiquiti |
The Apple MacBook Pro (Retina, 15-inch, Mid 2017 - A1707) delivers exceptional computing power and ultra-fast storage in a sleek, precision-milled aluminum unibody enclosure. Engineered for creative professionals, developers, and power users, it features a stunning 15.4-inch Retina display with LED backlighting, IPS technology, and P3 wide color gamut support, offering remarkable detail and color accuracy for photos and high-resolution video content.
At its core, this configuration is driven by a high-tier Quad-Core 3.1 GHz Intel Core i7 processor (Kaby Lake) with Turbo Boost speeds reaching up to 4.1 GHz. Equipped with dual graphics processing—Radeon Pro discrete graphics alongside integrated Intel HD Graphics 630—it automatically switches between processors to balance performance and battery efficiency. Packed with 16 GB of 2133 MHz LPDDR3 memory and an ultra-fast 1 TB PCIe-based onboard flash storage module, it delivers fluid multitasking and instant file access. The innovative Touch Bar with integrated Touch ID replaces the traditional function keys with dynamic, context-aware controls for maximum productivity.
Comprehensive Key Features:
Pro-Grade Quad-Core Performance: Powered by a 3.1 GHz Quad-Core Intel Core i7 processor (Turbo Boost up to 4.1 GHz) with 8 MB shared L3 cache.
Brilliant Retina Display with P3 Color: 15.4-inch IPS display featuring 500 nits brightness and P3 wide color gamut for true-to-life visual fidelity.
Interactive Touch Bar & Touch ID: Multi-Touch glass strip providing context-sensitive shortcuts alongside quick, secure Touch ID biometric authentication.
Dual Graphics Architecture: Combines discrete Radeon Pro graphics with integrated Intel HD Graphics 630 for efficient graphic rendering and power optimization.
Massive High-Speed Storage: Includes a large 1 TB PCIe-based onboard SSD delivering read/write speeds up to 3.2 GB/s.
Versatile Thunderbolt 3 Connectivity: Four high-speed USB-C / Thunderbolt 3 ports supporting power charging, DisplayPort output, and data transfers up to 40 Gbps.
Expansive Trackpad & Audio: Oversized Force Touch trackpad paired with high-fidelity stereo speakers featuring wide dynamic range and deep bass.
Extended Technical Specifications:
Model / SKU: MacBook Pro (15-inch, Mid 2017) / Model Identifier: MacBookPro14,3 / Model Number: A1707
Processor: 3.1 GHz Quad-Core Intel Core i7 (7700HQ "Kaby Lake", Turbo Boost up to 4.1 GHz) with 8 MB L3 cache
Graphics:
Discrete Graphics: AMD Radeon Pro 560 with 4 GB of GDDR5 memory (or Radeon Pro 555)
Integrated Graphics: Intel HD Graphics 630
Display: 15.4-inch (diagonal) LED-backlit IPS Retina display (2880 x 1800 native resolution at 220 ppi, 500 nits, P3 color)
Memory: 16 GB of 2133 MHz LPDDR3 onboard memory
Storage: 1 TB PCIe-based onboard flash storage
Wireless & Connectivity:
Wi-Fi: 802.11ac Wi-Fi wireless networking; IEEE 802.11a/b/g/n compatible
Bluetooth: Bluetooth 4.2 wireless technology
I/O Ports:
(4) Thunderbolt 3 (USB-C) ports (Supports Charging, DisplayPort, Thunderbolt 40 Gbps, USB 3.1 Gen 2 up to 10 Gbps)
(1) 3.5 mm headphone jack
Audio & Camera:
Stereo speakers with high dynamic range and 3 microphones
720p FaceTime HD camera
Keyboard & Input: Full-size backlit keyboard with Touch Bar and integrated Touch ID sensor; Force Touch trackpad
Battery & Power: Built-in 76.0-watt-hour lithium-polymer battery; 85W USB-C Power Adapter
