MikroTik SXT SA5 ac [EU ver.] RBSXTG-5HPacD-SA

The MikroTik SXT SA5 ac (Model: RBSXTG-5HPacD-SA) is a weatherproof, high-gain outdoor wireless Base Station designed for Wireless Internet Service Providers (WISPs), outdoor venues, and Point-to-Multipoint (PtMP) campus backhauls. Incorporating a wide 90-degree sector antenna with 14 dBi gain, it allows network operators to serve multiple subscriber CPE units across a wide area with high signal reliability.

Driven by a Qualcomm QCA9557 single-core processor operating at 720 MHz paired with 128 MB RAM and 128 MB NAND storage, the device delivers high data rates using 802.11ac wireless technology (with modulation up to 256-QAM and 80 MHz channel width support). Its high-output dual-chain 5 GHz wireless transmitter generates up to 1300 mW (31 dBm) output power for exceptional link budget performance over long distances.

For local network connectivity, the device includes a single 10/100/1000 Mbps Gigabit Ethernet port to prevent bandwidth bottlenecks, along with a USB 2.0 port for external storage or cellular modem attachments. It can be powered via Passive PoE (15–60 V) or standard 802.3af/at PoE. Housed in a durable, UV-stabilized outdoor enclosure with pole-mounting accessories included, the SXT SA5 ac operates on MikroTik RouterOS Level 4, supporting custom routing protocols, bandwidth queues, WISP protocols (NV2, Nstreme), and firewall controls.

Comprehensive Key Features

• Integrated 14 dBi 90° Sector Antenna: Provides wide dual-polarized sector coverage to connect multiple subscriber CPEs over long distances.

• High-Power 802.11ac Wireless Engine: Delivers up to 1300 mW (31 dBm) transmitter output power on the 5 GHz band for improved long-range performance.

• Gigabit Ethernet Uplink: Includes 1x 10/100/1000 Mbps RJ45 port to handle high wireless throughput without line-rate copper limitations.

• 802.3af/at & Passive PoE Support: Flexible powering options accepting 802.3af/at standard PoE or 15–60 V Passive PoE input.

• USB 2.0 Port: Full-sized USB Type-A interface for secondary storage expansion or 3G/4G cellular failover modems.

• RouterOS L4 WISP Software: Fully licensed RouterOS Level 4 software, ready for operation as a sector Access Point, bridge, or client unit.

Extended Technical Specifications

1. Hardware & Physical Parameters

• Model / SKU: RBSXTG-5HPacD-SA (SXT SA5 ac)

• Dimensions: 0.140 m × 0.140 m × 0.056 m (140 × 140 × 56 mm)

• Weight: 0.265 kg (265 g)

• CPU: QCA9557 Single-Core @ 720 MHz

• RAM: 128 MB

• Storage: 128 MB NAND

• USB Interface: 1× USB 2.0 Type-A Port

• Enclosure Material: UV-Stabilized Outdoor Weatherproof Casing

• Status LEDs: Power, User LED, Ethernet Link/Activity, 5x Wireless Signal Strength LEDs

2. Wireless, Networking & Performance Parameters

• Wireless Standards: 5 GHz (802.11a/n/ac dual-chain)

• Antenna Gain: 14 dBi

• Antenna Beamwidth: 90°

• Max TX Power: 31 dBm (1300 mW)

• Max Wireless Data Rate: Up to 867 Mbps

• Ethernet Ports: 1× 10/100/1000 Mbps RJ45 Port

• Operating System: MikroTik RouterOS (License Level 4)

• Architecture: MIPSBE

3. Electrical & Environmental Parameters

• Power Method: 802.3af/at PoE or Passive PoE-in (15 – 60 V DC)

• Included Power Accessories: 24 V DC / 0.8 A Power Adapter + Gigabit PoE Injector

• Max Power Consumption: 12 W

• Cooling Type: Passive

• Operating Temperature: -40°C to 70°C (-40°F to 158°F)
