The Ubiquiti Rocket 5AC Prism Gen2 (Model: R5AC-PRISM-G2) is an enterprise-grade 5\text{ GHz} outdoor wireless base station built for high-density Point-to-MultiPoint (PtMP) networks and high-throughput Point-to-Point (PtP) backhaul links. Powered by Ubiquiti's proprietary airMAX AC engine, the radio supports up to 500+\text{ Mbps} real TCP/IP throughput with high-density 256\text{QAM} modulation.
Designed for co-location deployment on high-density tower sites, the R5AC-PRISM-G2 incorporates airPrism active RF filtering technology. airPrism isolates signals within the operating channel and attenuates adjacent-channel interference by up to 30\text{ dB}, enabling superior co-location performance and link stability. The Gen2 platform integrates a dedicated 2.4\text{ GHz} Wi-Fi management radio for fast deployment using the UISP app, enhanced ESD/surge protection, and an IP67-rated die-cast aluminum housing for extreme environmental durability.
Comprehensive Key Features:
airPrism Active RF Filtering: Active selective filtering isolates operating channels to reduce co-location noise on crowded towers.
airMAX AC Protocol: Delivers up to 500+\text{ Mbps} real TCP/IP throughput with high-density 256QAM modulation and customized TDMA channel timing.
Dedicated Management Radio: Integrated 2.4\text{ GHz} Wi-Fi interface for quick device discovery, setup, and configuration using the mobile UISP app.
Die-Cast Aluminum Enclosure: Rugged, metal-shielded housing provides EMI protection and weatherproofing in severe environments.
GPS Synchronization: Hardware-synchronized frame timing allows co-located radios to transmit and receive synchronously, preventing mutual interference.
Seamless Antenna Integration: Features RP-SMA connectors and a quick-mount design compatible with RocketDish and airMAX Sector antennas.
Extended Technical Specifications:
1. Hardware & Physical Security:
Model / SKU: R5AC-PRISM-G2
Form Factor: Outdoor Tower / Pole Mount Radio
Dimensions: 268.0 x 88.0 x 43.0 mm (10.55 x 3.46 x 1.69")
Weight: 400 g (14.11 oz)
Enclosure Material: Die-Cast Aluminum with White Powder Coat
RF Connectors: (2) RP-SMA Weatherproof (Pass-Through) + (1) GPS Weatherproof
2. Networking, Performance & Radio Parameters:
Processor / Memory: Atheros MIPS 74Kc, 720 MHz | 128 MB DDR2 SDRAM, 16 MB NOR Flash
Networking Interface: (1) 10/100/1000 Mbps RJ45 Gigabit Ethernet Port
Management Radio: 2412–2472 MHz (Dedicated Wi-Fi Management)
Operating Frequency: 5150–5875 MHz (Worldwide)
Max. TX Power: 27 dBm
Throughput: 500+ Mbps
Channel Bandwidths: PtP Mode: 10/20/30/40/50/60/80 MHz | PtMP Mode: 10/20/30/40 MHz
3. Electrical, Environmental & Compliance Parameters:
Power Method: 24V Passive PoE (Pairs 4, 5+; 7, 8 Return)
Power Supply: 24V, 0.5A Gigabit PoE Adapter (Included)
Max. Power Consumption: 9.5W
Supported Voltage Range: 18–26V DC
ESD/EMP Protection: Air: \pm 24\text{ kV}, Contact: \pm 24\text{ kV}
Operating Temperature: -40°C to 80°C (-40°F to 176°F)
Operating Humidity: 5% to 95% Non-condensing
Certifications: CE, FCC, IC, RoHS Compliant
| brand | Ubiquiti |
The Apple MacBook Pro (Retina, 15-inch, Mid 2017 - A1707) delivers exceptional computing power and ultra-fast storage in a sleek, precision-milled aluminum unibody enclosure. Engineered for creative professionals, developers, and power users, it features a stunning 15.4-inch Retina display with LED backlighting, IPS technology, and P3 wide color gamut support, offering remarkable detail and color accuracy for photos and high-resolution video content.
At its core, this configuration is driven by a high-tier Quad-Core 3.1 GHz Intel Core i7 processor (Kaby Lake) with Turbo Boost speeds reaching up to 4.1 GHz. Equipped with dual graphics processing—Radeon Pro discrete graphics alongside integrated Intel HD Graphics 630—it automatically switches between processors to balance performance and battery efficiency. Packed with 16 GB of 2133 MHz LPDDR3 memory and an ultra-fast 1 TB PCIe-based onboard flash storage module, it delivers fluid multitasking and instant file access. The innovative Touch Bar with integrated Touch ID replaces the traditional function keys with dynamic, context-aware controls for maximum productivity.
Comprehensive Key Features:
Pro-Grade Quad-Core Performance: Powered by a 3.1 GHz Quad-Core Intel Core i7 processor (Turbo Boost up to 4.1 GHz) with 8 MB shared L3 cache.
Brilliant Retina Display with P3 Color: 15.4-inch IPS display featuring 500 nits brightness and P3 wide color gamut for true-to-life visual fidelity.
Interactive Touch Bar & Touch ID: Multi-Touch glass strip providing context-sensitive shortcuts alongside quick, secure Touch ID biometric authentication.
Dual Graphics Architecture: Combines discrete Radeon Pro graphics with integrated Intel HD Graphics 630 for efficient graphic rendering and power optimization.
Massive High-Speed Storage: Includes a large 1 TB PCIe-based onboard SSD delivering read/write speeds up to 3.2 GB/s.
Versatile Thunderbolt 3 Connectivity: Four high-speed USB-C / Thunderbolt 3 ports supporting power charging, DisplayPort output, and data transfers up to 40 Gbps.
Expansive Trackpad & Audio: Oversized Force Touch trackpad paired with high-fidelity stereo speakers featuring wide dynamic range and deep bass.
Extended Technical Specifications:
Model / SKU: MacBook Pro (15-inch, Mid 2017) / Model Identifier: MacBookPro14,3 / Model Number: A1707
Processor: 3.1 GHz Quad-Core Intel Core i7 (7700HQ "Kaby Lake", Turbo Boost up to 4.1 GHz) with 8 MB L3 cache
Graphics:
Discrete Graphics: AMD Radeon Pro 560 with 4 GB of GDDR5 memory (or Radeon Pro 555)
Integrated Graphics: Intel HD Graphics 630
Display: 15.4-inch (diagonal) LED-backlit IPS Retina display (2880 x 1800 native resolution at 220 ppi, 500 nits, P3 color)
Memory: 16 GB of 2133 MHz LPDDR3 onboard memory
Storage: 1 TB PCIe-based onboard flash storage
Wireless & Connectivity:
Wi-Fi: 802.11ac Wi-Fi wireless networking; IEEE 802.11a/b/g/n compatible
Bluetooth: Bluetooth 4.2 wireless technology
I/O Ports:
(4) Thunderbolt 3 (USB-C) ports (Supports Charging, DisplayPort, Thunderbolt 40 Gbps, USB 3.1 Gen 2 up to 10 Gbps)
(1) 3.5 mm headphone jack
Audio & Camera:
Stereo speakers with high dynamic range and 3 microphones
720p FaceTime HD camera
Keyboard & Input: Full-size backlit keyboard with Touch Bar and integrated Touch ID sensor; Force Touch trackpad
Battery & Power: Built-in 76.0-watt-hour lithium-polymer battery; 85W USB-C Power Adapter
